Gr65 Material Steel Power Pole with 460 MPa Yield Strength and 620 MPa Tensile Strength for High Voltage Transmission
Gr65 Material Steel Power Pole with 460 MPa Yield Strength and 620 MPa Tensile Strength for High Voltage Transmission
Propriétés de base
Lieu d'origine:
CHINE
Nom de la marque:
MilkyWay
Attestation:
ISO9001/BV/
Numéro de modèle:
Puissance Polonais en acier
Propriétés commerciales
Quantité minimum de commande:
1 pcs
Prix:
Négociable
Conditions de paiement:
T / t, l / c à la vue
Capacité d'approvisionnement:
300pcs par jour
Résumé du produit
35FT 70FT 90FT Bitumen Coated Steel Power Pole for High Voltage Power Transmission Line Product Specifications Types Length 45ft (13.75m) 50ft (15.25m) 55ft (16.80m) 60ft (18.30m) 65ft (19.85m) 70ft (21.35m) B (0°-2°) Top diameter (mm) 200 200 200 200 200 200 Butt diameter (mm) 345 370 395 415 435 ...
Attributs personnalisés du produit
Mettre en évidence
Gr65 Material Steel Power Pole
,460 MPa Yield Strength Electric Transmission Pole
,620 MPa Tensile Strength Galvanized Steel Pole
Nom de produit:
Puissance Polonais en acier
Application:
distribution de puissance
Matériel:
Gr 65
Limite conventionnelle d'élasticité minimum:
460 MPa
Résistance à la traction finale maximum:
MPA 620
Épaisseur de paroi:
1mm-36mm
Description du produit
Spécifications détaillées et caractéristiques
35FT 70FT 90FT Bitumen Coated Steel Power Pole for High Voltage Power Transmission Line
Product Specifications
| Types Length | 45ft (13.75m) | 50ft (15.25m) | 55ft (16.80m) | 60ft (18.30m) | 65ft (19.85m) | 70ft (21.35m) |
|---|---|---|---|---|---|---|
| B (0°-2°) | ||||||
| Top diameter (mm) | 200 | 200 | 200 | 200 | 200 | 200 |
| Butt diameter (mm) | 345 | 370 | 395 | 415 | 435 | 455 |
| Thickness (mm) | 6 | 6 | 6 | 6 | 6 | 6 |
| E (2°-15°) | ||||||
| Top diameter (mm) | 200 | 200 | 200 | 200 | 200 | 200 |
| Butt diameter (mm) | 545 | 585 | 625 | 660 | 700 | 740 |
| Thickness (mm) | 6 | 6 | 6 | 6 | 6 | 6 |
| C (15°-30°) | ||||||
| Top diameter (mm) | 250 | 250 | 250 | 250 | 250 | 250 |
| Butt diameter (mm) | 600 | 645 | 690 | 730 | 770 | 805 |
| Thickness (mm) | 6 | 6 | 6 | 6 | 6 | 6 |
| D (30°-90°) | ||||||
| Top diameter (mm) | 300 | 300 | 300 | 300 | 300 | 300 |
| Butt diameter (mm) | 680 | 730 | 725 | 765 | 755 | 790 |
| Thickness (mm) | 6 | 6 | 7 | 7 | 8 | 8 |
Material Description
- Poles are made by high-quality metal plants, molded into multi-row cone-shaped vertical steel bars with hot galvanized anti-corrosion treatment
- Light plate frame is made of high-quality stainless steel
- Fastened with stainless steel bolts and nuts
Our Services
1. Reply to your inquiry within 24 working hours
2. Experienced staff answer all questions in fluent English
3. Customized designs available (UEM&UBM welcomed)
4. Exclusive solutions provided by professional engineers
5. Special discounts and sales protection for distributors
6. Professional manufacturer with 20+ years experience in steel pole production
7. Samples available for testing (shipping charges may apply)
8. Superior raw materials and advanced manufacturing processes ensure high quality
Company Introduction
Jiangsu Milky Way Steel Poles, established in 1991 and located in Wuxi, China near Shanghai Port, specializes in manufacturing steel poles including transmission power poles, street light poles, and high mast poles.
With 24 years of experience, we have exported to over 70 countries including America, Australia, Russia, Germany, Spain, Philippines, Malaysia, and Africa.
Notable projects include supplying street light poles for Dubai Tower and high mast poles for the Sochi Winter Olympic Games.
